In this article, you will learn how to correctly set up the Honeywell Voyager 1250g barcode scanner and connect it to your Software. You will discover the benefits of the device, the different connection options, and how to carry out the setup step by step using the required barcodes.
In this article, you will find:
- Device description and benefits
- Supported connections and use cases
- Setup procedure with barcodes
- Tips to avoid errors
Fast lane
- Unpack the scanner and check that all parts are included
- Connect the scanner via USB or COM port
- Cover all barcodes you do not want to scan
- Scan the setup barcodes in the specified order
- Select the connection type (USB, COM port) and scan the barcode
- Test the device
Device description and benefits
The Honeywell Voyager 1250g is a high-performance single-line laser scanner developed especially for retail environments. It reliably reads barcodes even when they are damaged or poorly printed. The extended depth of field (0 mm to 446 mm) allows fast operation without precise aiming.
Thanks to its robust construction (IP41 protection class), the scanner can withstand up to 30 drops from a height of 1.5 meters – ideal for daily use in the studio or shop.
Supported connections and use cases
The scanner supports various interfaces, giving you flexibility:
- USB (virtual COM port)
- RS-232 (classic COM port)
- Virtual COM port via LAN adapter (TCP Websockets)
Depending on your setup, you can configure the appropriate connection to optimally integrate the scanner into your System.
Setup procedure with barcodes
Before you start: Cover all barcodes you do not want to scan to avoid incorrect configurations.
Procedure:
- Connect the scanner to your PC or terminal.
- Scan the barcodes below in the specified order.
1. Basic settings – set defaults
2. USB Serial Emulation – select operating system
- Select your connection mode:
- USB virtual COM port
- RS-232 COM port
To do this, scan the corresponding configuration barcode from the manual.
4. Test the scanner by scanning any barcode and checking whether it appears correctly on the PC.
Tips to avoid errors
- Only scan the desired setup barcode to avoid incorrect configurations.
- Make sure the scanner is stable during configuration.
- If the scanner is not recognized, check the connection (USB/COM port) and restart the PC.
